Yamaha Tenere 700 Rear Shock X-TREME + HPA Lowered -35mm
€ 1.321,00
Excl. VAT
Excl. VAT
Excl. VAT
€ 1.321,00
Excl. VAT
Excl. VAT
Excl. VAT
SKU
46YA19-T5514-TO
Product Line
X-TREME
Product Type
Shock
Brand
Yamaha
Model
Tenere 700
Model Year
2019 - 2024
Height
Lowered -35mm
Installation location
REAR
Damping adjustment
Rebound & Compression High + Low Speed
Damping system
Separated oil/gas with reservoir
Damping feature
PDSII anti-bottoming
Piston diameter (mm)
46
Preload adjustment
Hydraulic, with knob
Spring type
Linear, included
Spring rate default (N/mm)
85
Special remark
Side and/or center stand might be too long
Rebound Position
10 (270 deg)
High Speed Compression Position
8
Low Speed Compression Position
8
Preload Spring (mm)
23 +5/-5
Spring -2 (Rate-Length)
75-180
Spring -1 (Rate-Length)
80-180
Spring default (Rate-Length)
85-180
Spring +1 (Rate-Length)
90-180
Spring +2 (Rate-Length)
95-180
Spring -2 Stock Code
46100106
Spring -1 Stock Code
46100107
Spring default Stock Code
46100107
Spring +1 Stock Code
46100090
Spring +2 Stock Code
46100091
Shock Length
359
Stroke M to M
85
Pressure
15
Bottom Angle A
200
Pa Angle A
220 H/195 Kn
Pa Angle B
Straight
Pa Angle C
325
Pa Angle D
320
Reservoir Length
100.00
Mount Upper Diameter
12.00
Mount Upper Width
35
Mount Lower Diameter
12.00
Mount Lower Width
30 (fork)
Remarks1
Fit knob on bracket and rotate tension away
Remarks2
Uni.bracket between contranuts. Set retainer first
Remarks3
Spacer on top of PA bracket. Springret.46000229
