BMW R 1200 GS Front Shock X-TREME
€ 1.073,00
Excl. VAT
Excl. VAT
Excl. VAT
€ 1.073,00
Excl. VAT
Excl. VAT
Excl. VAT
SKU
46BM13-T5140-TO
Product Line
X-TREME
Product Type
Shock
Brand
BMW
Model
R 1200 GS
Model Year
2013 - 2017
Height
Standard
Installation location
Front
Damping adjustment
Rebound & Compression High + Low Speed
Damping system
Separated oil/gas with reservoir
Damping feature
PDSII anti-bottoming
Piston diameter (mm)
46
Preload adjustment
Mechanical
Spring type
Linear, included
Spring rate default (N/mm)
50
Rebound Position
10 (180 deg)
High Speed Compression Position
12
Low Speed Compression Position
12
Preload Spring (mm)
9
Spring -1 (Rate-Length)
48-205
Spring default (Rate-Length)
50-205
Spring +1 (Rate-Length)
55-205
Spring +2 (Rate-Length)
60-205
Spring -1 Stock Code
46100141
Spring default Stock Code
46100033
Spring +1 Stock Code
46100034
Spring +2 Stock Code
46100035
Shock Length
389
Stroke M to M
95
Pressure
15
Bottom Angle A
180
Reservoir Length
100.00
Mount Upper Diameter
10.00
Mount Upper Width
22
Mount Lower Diameter
10.00
Mount Lower Width
22
Remarks1
PDSII inside
Remarks2
Langste LVB rechts
Remarks3
Bottom under let op sticker
